| *Front Hub | Size: ML , M , XXS , XS , L , S , XL
Formula DC-20, alloy, 6-bolt, 5x100mm QR
|
|---|---|
| *Rear Hub | Size: ML , M , XXS , XS , L , S , XL
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
|
| *Rear Skewer | Size: ML , M , XXS , XS , L , S , XL173x5mm QR |
| *Rim | Size: ML , M , XXS , XS , L , S , XL
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
|
| *Tire | Size: XXS
Bontrager Montrose Comp, wire bead, 30 tpi, 26x2.35''
|
| Size: XS , S
Bontrager Montrose comp, wire bead, 30 tpi, 27.5x2.40''
|
|
| Size: ML , M , L , XL
Bontrager Montrose comp, wire bead, 30 tpi, 29x2.40''
|
Drivetrain
| *Shifter | Size: ML , M , XXS , XS , L , S , XL
Shimano M315, 8 speed
|
|---|---|
| *Rear Derailleur | Size: ML , M , XXS , XS , L , S , XL
Shimano ESSA U2000
|
| *Crank | Size: XXS , XS
ProWheel alloy, 32T narrow-wide steel ring, 160mm length
|
| Size: ML , M , S
ProWheel alloy, 32T narrow-wide steel ring, 170mm length
|
|
| Size: L , XL
ProWheel alloy, 32T narrow-wide steel ring, 175mm length
|
|
| *Cassette | Size: ML , M , XXS , XS , L , S , XL
Shimano HG300, 11-45, 8 speed
|
| *Chain | Size: ML , M , XXS , XS , L , S , XL
KMC Z8.3, 8 speed
|
| *Pedal | Size: ML , M , XXS , XS , L , S , XL
nylon platform
|
Components
| *Saddle | Size: ML , M , XXS , XS , L , S , XLBontrager Verse Short, stainless steel rails |
|---|---|
| *Seatpost | Size: XXS
Bontrager alloy, 31.6mm, 12mm offset, 300mm length
|
| Size: M , XS , S
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
|
|
| Size: ML , L , XL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length
|
|
| *Handlebar | Size: XXS , XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
|
| Size: S
Bontrager alloy, 31.8mm, 15mm rise, 720mm width
|
|
| Size: ML , M , L , XL
Bontrager alloy, 31.8mm, 15mm rise, 750mm width
|
|
| *Grips | Size: ML , M , XXS , XS , L , S , XLTrek Line Comp, nylon lock-on |
| *Stem | Size: XXS , XS , S
Bontrager Comp, 31.8mm, 7 degree, 35mm length
|
| Size: ML , M , LBontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length | |
| Size: XLBontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length | |
| *Headset | Size: ML , M , XXS , XS , L , S , XL
Semi-integrated, 1-1/8''
|
| *Brake | Size: XXS , XS , S
Tektro HD-M276 hydraulic disc
|
| Size: ML , M , L , XL
Tektro HD-M275 hydraulic disc
|
|
| *Brake Rotor | Size: ML , M , XXS , XS , L , S , XL
Tektro, 6-bolt, 160mm
|
| Size: ML , M , L , XL
Tektro, 6-bolt, 180mm
|
Weight
| Weight | M - 14.90 kg / 32.85 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
SIZING:
How tall are you?
To measure your height, stand straight up, barefoot, with your back, heels, shoulders and head all touching a wall. While looking straight ahead, place a book or straight edge on your head and slowly push it against the wall. Your straight edge should be parallel with the floor. Mark the spot where the bottom of the book is touching the wall. The distance from the marked spot to the floor is your height.
