Why you'll love it

1. This is our lightest hybrid e-bike, making it easier to maneuver while parking and less of a pain to carry up stairs
2. The pedal assist system has a hub motor for a more natural ride feel and a simple LED remote that indicates your assist setting
3. Stiff wheels and wide tires give you the terrain-smoothing comfort and confidence of a suspension fork without the added weight
4. It's easy to accessorize with fenders and a rear rack to carry everything you need
5. Double your range with a 250Wh plug-and-play Range Extender battery that uses water bottle mounts to attach to your frame

Weight

Weight	M - 17.28 kg / 38.1 lbs
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

How tall are you?

To measure your height, stand straight up, barefoot, with your back, heels, shoulders and head all touching a wall. While looking straight ahead, place a book or straight edge on your head and slowly push it against the wall. Your straight edge should be parallel with the floor. Mark the spot where the bottom of the book is touching the wall. The distance from the marked spot to the floor is your height.

What is your inseam?

How to measure: Stand barefoot with your back straight and against a wall. Tuck a ruler or something that extends to the floor between your legs. Using both hands, and keeping it level, pull the ruler up into your crotch as if you were sitting on the saddle. Measure the distance from the top edge of the ruler to the ground to find your inseam measurement. Your inseam is very important to your final bike size so please measure carefully.

Sizing

size-table

Size	Rider Height	Inseam
S	155 - 165 cm 5'1" - 5'5"	72 - 78 cm 28" - 31"
M	165 - 175 cm 5'5" - 5'9"	77 - 83 cm 30" - 33"
L	175 - 186 cm 5'9" - 6'1"	82 - 88 cm 32" - 35"



Geometry

All measurements provided in cm unless otherwise noted.

Sizing table

Frame size number	Frame size letter	Wheel size	A — Seat tube	B — Seat tube angle	C — Head tube length	D — Head angle	E — Effective top tube	F — Bottom bracket height	G — Bottom bracket drop	H — Chainstay length	I — Offset	J — Trail	K — Wheelbase	L — Standover	M — Frame reach	N — Frame stack
45cm	S	27.5"	40.8	73.5°	15.5	70.0°	56.9	27.8	7.0	46.8	5.0	7.6	109.2	65.5	38.2	60.4
50cm	M	27.5"	46.3	73.0°	17.0	70.5°	57.4	27.8	7.0	46.8	5.0	7.3	109.5	67.2	38.5	62.0
55cm	L	27.5"	50.7	73.0°	20.0	71.0°	59.2	27.8	7.0	46.8	5.0	6.9	110.9	69.3	39.3	65.0
