Trek Domane AL 4 Gen 4 (2026)

Specifications
Weight	56 - 10.35 kg / 22.82 lbs
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

Drivetrain

Specifications
*Shifter	Size: 44, 56, 58, 49, 61, 52, 54 Shimano Tiagra R4720, 10 speed
*Front Derailleur	Size: 44, 56, 58, 49, 61, 52, 54 Shimano Tiagra 4700, 31.8mm clamp
*Rear Derailleur	Size: 44, 56, 58, 49, 61, 52, 54Shimano Tiagra 4700, long cage, 34T max cog
*Crank	Size: 44 Shimano Tiagra 4700, 50/34, 165mm length
	Size: 49, 52Shimano Tiagra 4700, 50/34, 170mm length
	Size: 56, 54Shimano Tiagra 4700, 50/34, 172.5mm length
	Size: 58, 61Shimano Tiagra 4700, 50/34, 175mm length
*Bottom Bracket	Size: 44, 56, 58, 49, 61, 52, 54 Shimano RS501 BSA
*Cassette	Size: 44, 56, 58, 49, 61, 52, 54Shimano HG500, 11-32, 10 speed
*Chain	Size: 44, 56, 58, 49, 61, 52, 54 Shimano Tiagra HG54, 10 speed
Max chainring size	1x: 50T, 2x: 50/34

Wheels

Specifications
*Front Hub	Size: 44, 56, 58, 49, 61, 52, 54 Formula RX-512 alloy, 6-bolt, 100x12mm thru axle
*Front Skewer	Size: 44, 56, 58, 49, 61, 52, 54Bontrager Switch chamfered thru axle
*Rear Hub	Size: 44, 56, 58, 49, 61, 52, 54 Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142x12mm thru axle
*Rear Skewer	Size: 44, 56, 58, 49, 61, 52, 54Bontrager Switch chamfered thru axle, removable lever
*Rim	Size: 44, 56, 58, 49, 61, 52, 54 Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21mm width, Presta valve
*Spokes	Size: 44, 56, 58, 49, 61, 52, 54 14g stainless steel, black
*Tire	Size: 44, 56, 58, 49, 61, 52, 54 Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32mm

Components

Specifications
*Saddle	Size: 44, 56, 58, 49, 61, 52, 54Verse Short, steel rails, 145mm width
*Seatpost	Size: 44, 49 Bontrager Comp, 6061 alloy, 27.2mm, 8mm offset, 250mm length
*Seatpost	Size: 56, 58, 61, 52, 54 Bontrager Comp, 6061 alloy, 27.2mm, 8mm offset, 330mm length
*Handlebar	Size: 44Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control width, 40cm drop width
	Size: 44, 49Bontrager Comp VR-S, alloy, 31.8mm, 81mm reach, 118mm drop, 38cm width
	Size: 49Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm drop width
	Size: 52Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control width, 44cm drop width
	Size: 52Bontrager Comp VR-S, alloy, 31.8mm, 81mm reach, 118mm drop, 40cm width
	Size: 56, 54Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm drop width
	Size: 56, 54Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 42cm width
	Size: 58, 61Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 44cm control width, 48cm drops width
	Size: 58, 61Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 44cm width
*Handlebar Tape	Size: 44, 56, 58, 49, 61, 52, 54 Bontrager Supertack Perf tape
*Stem	Size: 44Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
	Size: 49Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
	Size: 52, 54Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
	Size: 56, 58Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length
	Size: 61Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length
*Brake	Size: 44, 56, 58, 49, 61, 52, 54 Shimano Tiagra hydraulic disc, flat mount
*Brake Rotor	Size: 44, 56, 58, 49, 61, 52, 54 Shimano RT66, 6-bolt, 160mm
Rotor size	Max brake rotor sizes: 160mm front & rear

How tall are you?

To measure your height, stand straight up, barefoot, with your back, heels, shoulders and head all touching a wall. While looking straight ahead, place a book or straight edge on your head and slowly push it against the wall. Your straight edge should be parallel with the floor. Mark the spot where the bottom of the book is touching the wall. The distance from the marked spot to the floor is your height.

What is your inseam?

How to measure: Stand barefoot with your back straight and against a wall. Tuck a ruler or something that extends to the floor between your legs. Using both hands, and keeping it level, pull the ruler up into your crotch as if you were sitting on the saddle. Measure the distance from the top edge of the ruler to the ground to find your inseam measurement. Your inseam is very important to your final bike size so please measure carefully.

Sizing

size-table
Size	Rider Height	Inseam
44	150 - 153 cm 4'11" - 5'0"	71 - 73 cm 28" - 29"
49	156 - 163 cm 5'1" - 5'4"	74 - 77 cm 29" - 30"
52	163 - 168 cm 5'4" - 5'6"	76 - 79 cm 30" - 31"
54	168 - 174 cm 5'6" - 5'9"	78 - 82 cm 31" - 32"
56	174 - 180 cm 5'9" - 5'11"	81 - 85 cm 32" - 33"
58	180 - 185 cm 5'11" - 6'1"	84 - 87 cm 33" - 34"
61	185 - 191 cm 6'1" - 6'3"	86 - 90 cm 34" - 35"

Geometry

All measurements provided in cm unless otherwise noted.

Sizing table
Frame size number	Wheel size	A — Seat tube	B — Seat tube angle	C — Head tube length	D — Head angle	E — Effective top tube	G — Bottom bracket drop	H — Chainstay length	I — Offset	J — Trail	K — Wheelbase	L — Standover	M — Frame reach	N — Frame stack
44cm	700c	39.0	74.6°	9.5	70.3°	50.7	8.0	42.0	5.3	6.6	98.3	65.7	36.0	51.0
49cm	700c	44.0	74.6°	12.3	70.8°	51.6	8.0	42.5	5.3	6.6	100.1	71.7	36.8	54.0
52cm	700c	47.5	74.2°	14.5	71.3°	53.0	8.0	42.0	5.3	5.9	100.3	73.5	37.1	56.1
54cm	700c	50.0	73.7°	16.0	71.3°	54.2	8.0	42.0	5.3	5.9	101.0	75.4	37.4	57.5
56cm	700c	52.5	73.3°	17.5	71.9°	55.4	7.8	42.0	4.8	6.1	101.8	77.6	37.7	59.1
58cm	700c	54.8	73.0°	19.5	72.0°	56.7	7.8	42.5	4.8	6.0	102.2	79.6	38.0	61.1
61cm	700c	57.6	72.7°	23.5	72.1°	58.6	7.5	42.5	4.8	6.3	103.8	84.2	38.5	64.6
