Checkpoint ALR 5

$2,499.99
Availability: In stock (1)
Delivery time: Pick up in store only

Checkpoint ALR 5 is the best value gravel bike in the lineup. It's a high-quality build that will hold up for long, rugged miles on pavement, dirt, and even the most treacherous gravel roads. A wealth of features like nimble-yet-stable progressive geometry, loads of mounts, plus a GRX drivetrain make it easy to customize for your kind of adventure.

It's right for you if...

Unlike the pure roadie who measures watts and weighs out meals, you favor epic off-road adventures that probably end with a beer and a burrito. But that doesn't mean you'll compromise on performance. You expect to get a lot for your hard-earned dollar, including quality, versatility, durability, and a ridiculous amount of fun.

The tech you get

A sturdy aluminum frame with a progressive geometry that's stable at speed and efficient when you're grinding up a climb, hidden cables that won't interfere with bags, rack and fender mounts and integrated frame bag mounts, a 2x11 Shimano GRX drivetrain with lower gears for grinding up hills or through rough gravel, hydraulic disc brakes for all-condition stopping power, tubeless ready rims, and wide 700x40c gravel tires for added stability and traction.

The final word

If the amount of adventure you can get per dollar spent is a priority for you, you won't do better than Checkpoint ALR 5. Quality parts, a durable alloy frame, and a wealth of features like extra tire clearance and customization options— so you can confidently take on bigger, better adventures.



The Walkthrough

favorite_borderWhy you'll love it

  1. All-new progressive geometry is quick and nimble yet keeps you stable and in control on fast, choppy descents
  2. This bike is exceedingly versatile and suited to a wide variety of ride styles, including gravel rides, bikepacking, and daily commutes
  3. Massive tire clearance means you can use tires up to 45c for extra traction and stability in any conditions
  4. Integrated frame bag mounts and rack and fender mounts make it easy to carry gear and water
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing.

Specifications

*spec applies to all sizes unless otherwise noted

Frameset
expand_less
Frame 300 Series Alpha Aluminum, tapered head tube, Internal cable routing, 3S chain keeper, T47 BB, rack and fender mounts, integrated frame bag mounts, flat mount disc, 142x12mm thru axle
Frame fit Gravel
Wheels
expand_less
Hub front Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle
Skewer front Bontrager Switch thru axle, removable lever
Hub rear Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
Skewer rear Bontrager Switch thru axle, removable lever
*Rim Size: 49, 52, 54, 56, 58, 61
Bontrager Paradigm, Tubeless Ready, 24-hole, 21mm width, presta valve
Size: 49, 52, 54, 56, 58, 61
Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21mm width, presta valve
Spokes 14g stainless steel
Tire Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi, 700x40c
Tire part Bontrager TLR sealant, 6oz
Rim strip Bontrager Aeolus XXX rim strip
Max tire size 700x45c / 650x2.1" Bontrager tires
Drivetrain
expand_less
Shifter Shimano GRX RX600, 11 speed
Front derailleur Shimano GRX RX810, braze-on
Rear derailleur Shimano GRX RX810, long cage, 34T max cog
*Crank Size: 49
Shimano GRX RX600, 46/30, 165mm length
Size: 52
Shimano GRX RX600, 46/30, 170mm length
Size: 54, 56
Shimano GRX RX600, 46/30, 172.5mm length
Size: 58, 61
Shimano GRX RX600, 46/30, 175mm length
Bottom bracket Praxis, T47 threaded, internal bearing
Cassette Shimano 105 HG700-11, 11-34, 11 speed
Chain Shimano HG601
Max chainring size 1x: 44T SRAM or 50T Shimano, 2x: 50/34
Components
expand_less
*Saddle Size: 49, 52
Bontrager P3 Verse Comp, steel rails, 155mm width
Size: 54, 56, 58, 61
Bontrager P3 Verse Comp, steel rails, 145mm width
Seatpost Bontrager alloy, 27.2mm, 12mm offset, 330mm length
*Handlebar Size: 49
Bontrager Elite Gravel, 38cm width
Size: 52
Bontrager Elite Gravel, 40cm width
Size: 54, 56
Bontrager Elite Gravel, 42cm width
Size: 58, 61
Bontrager Elite Gravel, 44cm width
Handlebar tape Bontrager Supertack Perf tape
*Stem Size: 49
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: 52, 54
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: 56, 58
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
Size: 61
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length
Headset FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Brake rotor Shimano SM-RT70, centerlock, 160mm
Rotor size Max brake rotor sizes: 160mm front & rear
Weight
expand_less
Weight 56 - 9.75 kg / 21.5 lbs
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

Sizing & Tech

The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit. That’s why you’ll see some overlap in our recommendations. Not every rider who’s 5´8˝, for example, will fit on the same size bike. The best way to find your perfect fit is to consult the experts at your local retailer.

Size Rider Height Inseam
49

156 - 163 cm

5'1.4" - 5'4.2"

74 - 77 cm

29.1" - 30.3"

52

163 - 168 cm

5'4.2" - 5'6.1"

76 - 79 cm

29.9" - 31.1"

54

168 - 174 cm

5'6.1" - 5'8.5"

78 - 82 cm

30.7" - 32.3"

56

174 - 180 cm

5'8.5" - 5'10.9"

81 - 85 cm

31.9" - 33.5"

58

180 - 185 cm

5'10.9" - 6'0.8"

84 - 87 cm

33.1" - 34.3"

61

185 - 191 cm

6'0.8" - 6'3.2"

86 - 90 cm

33.9" - 35.4"



All measurements provided in cm unless otherwise noted.

Frame size number Wheel size A — Seat tube B — Seat tube angle C — Head tube length D — Head angle E — Effective top tube G — Bottom bracket drop H — Chainstay length I — Offset J — Trail K — Wheelbase L — Standover M — Frame reach N — Frame stack Stem length
49 cm 700c 49.0 74.1° 9.0 71.2° 54.1 7.8 43.5 4.5 7.4 102.5 73.5 39.3 53.8 70.0
52 cm 700c 52.0 73.7° 10.5 71.6° 55.5 7.8 43.5 4.5 7.1 103.3 76.5 39.9 55.3 80.0
54 cm 700c 54.0 73.2° 12.5 71.8° 57.0 7.6 43.5 4.5 7.0 104.1 78.9 40.3 57.1 80.0
56 cm 700c 56.0 72.8° 14.5 72.2° 58.4 7.6 43.5 4.5 6.7 104.8 80.9 40.7 59.2 90.0
58 cm 700c 58.0 72.5° 16.5 72.3° 59.7 7.4 43.5 4.5 6.6 105.8 82.9 41.1 60.9 90.0
61 cm 700c 61.0 72.1° 19.5 72.6° 61.7 7.4 43.5 4.5 6.5 107.0 85.9 41.7 63.9 100.0
